Above Ground Insulator Tester – Model RF-IT Precision Testing for Pipeline and Flange Bolt Insulation

Description

The Above Ground Insulator Tester (Model RF-IT) is a portable, handheld diagnostic tool designed to test the effectiveness of above-ground pipeline insulators and detect electrical shorts, especially in flange bolts. Utilizing radio frequency (RF) technology, this tester provides pinpoint accuracy in locating insulation failures—making it an essential tool for pipeline maintenance professionals.

Engineered for use on structures with or without cathodic protection (CP), the RF-IT Above Ground Insulator Tester emits an audible signal that increases in frequency as it nears a fault, while an LCD sliding scale visually confirms proximity. Whether you’re checking insulators or tracing shorts bolt-to-bolt, this rugged and reliable tester delivers fast, accurate results.

Product Benefits

• Pinpoint Fault Detection – RF signal and LCD scale work in tandem to locate shorts and contact points with high precision.
• Easy to Use – Move probe bolt-to-bolt or across insulators with immediate audible and visual feedback.
• Versatile – Effective on both CP-protected and non-CP structures.
• Portable and Durable – Lightweight handheld design with a tough polypropylene case, ideal for field work.
• Time-Saving Auto Shut-Off – Conserves battery life during inactive periods.
• Cost-Effective – Quickly identifies faults without the need for disassembly or more invasive inspection methods.

Typical Applications

• Testing above ground insulators on pipelines
• Locating flange bolt shorts
• Evaluating structures with or without cathodic protection
• Pinpointing contact points in insulated pipeline supports
• Field inspections and maintenance of pipeline support systems

What’s Included in the RF-IT Kit

• RF-IT Instrument with LCD meter and audible alarm
• 9V Battery (installed)
• Red Probe with lead wire and needle point tip
• Black Probe with needle point tip
• Extra needle tips in protective vinyl tubes
• Instruction Manual
• Certificate of Calibration
• Warranty Card

For accurate, efficient, and non-destructive testing of pipeline insulation integrity, the Above Ground Insulator Tester (Model RF-IT) from Unconventional Solutions is your go-to field tool. Ensure safety, prevent corrosion issues, and keep your systems running smoothly with this compact and powerful insulator tester.
